Description:

All DR-Systems require longer wheel bolts. These must be ordered separately. H&R Wheel Spacer Bolts are listed here. When ordering wheel bolts, please follow these guidelines: a) If possible, name the brand of wheel. b) New bolts must be longer than the original bolts by the width of the wheel spacer used. c) The bolt head must be identical to the existing bolt: Taper 60 End digit 01 Round head for M12/d24 mm, for M14/d28 mm End digit 02 Round head for M12/d26 mm (e.g. OE VAG-wheels) End digit 03 Flat head for Porsche original wheels M14 x 1.5 End digit 06 d) Safety guidelines (Minimum number of turns for wheel bolts / nuts): M12 x 1.25 = 8.0 turns = approx. 10 mm of load bearing shaft length M12 x 1.50 = 6.5 turns = approx. 10 mm of load bearing shaft length M12 x 1.75 = 6.5 turns = approx. 12 mm of load bearing shaft length M14 x 1.25 = 9.0 turns = approx. 12mm of load bearing shaft length M14 x 1.50 = 7.5 turns = approx. 12 mm of load bearing shaft length 1/2" UNF = 8.0 turns = approx. 11 mm of load bearing shaft length e) Please ensure that the wheel bolts do not damage any part of the brake system (ABS sensors, etc.). Turn the wheel by hand and check clearance on the inside of the hub. The wheel should rotate freely. (Maximum tolerance for some vehicles is only 2mm -- i.e. Rear Axle Mercedes).

This Part Fits:

Year	Make	Model	Submodel
2023-2025	Volvo	S60	B5 Core
2022	Volvo	S60	B5 Inscription
2022	Volvo	S60	B5 Momentum
2023-2025	Volvo	S60	B5 Plus
2022	Volvo	S60	B5 R-Design
2023-2024	Volvo	S60	B5 Ultimate
2025	Volvo	S60	B5 Ultra
2025	Volvo	S60	B5 Ultra Black Edition
2021	Volvo	S60	Recharge R-Design
2019-2021	Volvo	S60	T5 Inscription
2019-2021	Volvo	S60	T5 Momentum
2019-2021	Volvo	S60	T5 R-Design
2019-2021	Volvo	S60	T6 Inscription
2019-2021	Volvo	S60	T6 Momentum
2019-2021	Volvo	S60	T6 R-Design
2025	Volvo	S60	T8 Core
2019-2020	Volvo	S60	T8 Inscription
2025	Volvo	S60	T8 Plus
2020	Volvo	S60	T8 Polestar
2019-2020	Volvo	S60	T8 R-Design
2023-2024	Volvo	S60	T8 Recharge Core
2021-2022	Volvo	S60	T8 Recharge Inscription
2023-2024	Volvo	S60	T8 Recharge Plus
2021-2023	Volvo	S60	T8 Recharge Polestar
2021-2022	Volvo	S60	T8 Recharge R-Design
2021-2022	Volvo	S60	T8 Recharge R-Design Expression
2023-2024	Volvo	S60	T8 Recharge Ultimate
2025	Volvo	S60	T8 Ultra
2025	Volvo	S60	T8 Ultra Black Edition
2023-2025	Volvo	XC40	B5 Core
2023-2025	Volvo	XC40	B5 Plus
2023-2025	Volvo	XC40	B5 Ultimate
2019-2022	Volvo	XC40	T5 Inscription
2019-2022	Volvo	XC40	T5 Momentum
2019-2022	Volvo	XC40	T5 R-Design
2023-2025	Volvo	XC60	B5 Core
2022	Volvo	XC60	B5 Inscription
2022	Volvo	XC60	B5 Momentum
2023-2025	Volvo	XC60	B5 Plus
2022	Volvo	XC60	B5 R-Design
2023-2024	Volvo	XC60	B5 Ultimate
2025	Volvo	XC60	B5 Ultra
2025	Volvo	XC60	B5 Ultra Black Edition
2022	Volvo	XC60	B6 Inscription
2022	Volvo	XC60	B6 R-Design
2023	Volvo	XC60	B6 Ultimate
2018-2021	Volvo	XC60	T5 Inscription
2018-2021	Volvo	XC60	T5 Momentum
2018-2021	Volvo	XC60	T5 R-Design
2018-2021	Volvo	XC60	T6 Inscription
2018-2021	Volvo	XC60	T6 Momentum
2018-2021	Volvo	XC60	T6 R-Design
2025	Volvo	XC60	T8 Core
2018-2020	Volvo	XC60	T8 Inscription
2018-2020	Volvo	XC60	T8 Momentum
2025	Volvo	XC60	T8 Plus
2020,2025	Volvo	XC60	T8 Polestar
2018-2020	Volvo	XC60	T8 R-Design
2023-2024	Volvo	XC60	T8 Recharge Core
2021-2022	Volvo	XC60	T8 Recharge Inscription
2021-2022	Volvo	XC60	T8 Recharge Inscription Expression
2023-2024	Volvo	XC60	T8 Recharge Plus
2021-2024	Volvo	XC60	T8 Recharge Polestar
2021-2022	Volvo	XC60	T8 Recharge R-Design
2023-2024	Volvo	XC60	T8 Recharge Ultimate
2025	Volvo	XC60	T8 Ultra
2025	Volvo	XC60	T8 Ultra Black Edition
