H&R Trak+ 18mm DR Wheel Adaptor Bolt 5/130 Center Bore 71.6 Bolt Thread 14x1.5 - Black H&R Trak+ 18mm DR Wheel Adaptor Bolt 5/130 Center Bore 71.6 Bolt Thread 14x1.5 - Black
H&R Trak+ 18mm DR Wheel Adaptor Bolt 5/130 Center Bore 71.6 Bolt Thread 14x1.5 - Black

Manufacturer: H&R
Manufacturer Part Number: HRS36957161SW

Description:

All DR-Systems require longer wheel bolts. These must be ordered separately. H&R Wheel Spacer Bolts are listed here. When ordering wheel bolts, please follow these guidelines: a) If possible, name the brand of wheel. b) New bolts must be longer than the original bolts by the width of the wheel spacer used. c) The bolt head must be identical to the existing bolt: Taper 60 End digit 01 Round head for M12/d24 mm, for M14/d28 mm End digit 02 Round head for M12/d26 mm (e.g. OE VAG-wheels) End digit 03 Flat head for Porsche original wheels M14 x 1.5 End digit 06 d) Safety guidelines (Minimum number of turns for wheel bolts / nuts): M12 x 1.25 = 8.0 turns = approx. 10 mm of load bearing shaft length M12 x 1.50 = 6.5 turns = approx. 10 mm of load bearing shaft length M12 x 1.75 = 6.5 turns = approx. 12 mm of load bearing shaft length M14 x 1.25 = 9.0 turns = approx. 12mm of load bearing shaft length M14 x 1.50 = 7.5 turns = approx. 12 mm of load bearing shaft length 1/2" UNF = 8.0 turns = approx. 11 mm of load bearing shaft length e) Please ensure that the wheel bolts do not damage any part of the brake system (ABS sensors, etc.). Turn the wheel by hand and check clearance on the inside of the hub. The wheel should rotate freely. (Maximum tolerance for some vehicles is only 2mm -- i.e. Rear Axle Mercedes).

Installation Instructions
User 1

This Part Fits:

Year Make Model Submodel
2007-2010 Audi Q7 Base
2007-2015 Audi Q7 Premium
2011-2015 Audi Q7 Premium Plus
2010-2015 Audi Q7 Prestige
2009-2010 Audi Q7 TDI
2011-2015 Audi Q7 TDI Premium
2011-2015 Audi Q7 TDI Premium Plus
2011-2015 Audi Q7 TDI Prestige
2018-2019 Porsche 718 Boxster GTS
2018-2019 Porsche 718 Cayman GTS
1998-2019 Porsche 911 Carrera
1999-2004,2013-2024 Porsche 911 Carrera 4
2004,2013-2024 Porsche 911 Carrera 4S
2015-2016,2018-2019 Porsche 911 Carrera GTS
2012-2019 Porsche 911 Carrera S
2002-2004,2008 Porsche 911 GT2
2011 Porsche 911 GT2 RS
2001-2005,2007-2008,2014-2019 Porsche 911 Turbo
2005,2014-2019 Porsche 911 Turbo S
1997-1999,2004-2011 Porsche Boxster Base
2008 Porsche Boxster Limited Edition
2000-2003 Porsche Boxster Roadster
2000-2003 Porsche Boxster Roadster S
2008 Porsche Boxster RS 60 Spyder
2004-2011 Porsche Boxster S
2008 Porsche Boxster S Limited Edition
2009 Porsche Boxster S Porsche Design 2
2004 Porsche Boxster S Special Edition
2011 Porsche Boxster Spyder
2004-2006,2008-2014,2016-2018 Porsche Cayenne Base
2013-2016 Porsche Cayenne Diesel
2014 Porsche Cayenne Diesel Platinum Edition
2008-2010,2013-2018 Porsche Cayenne GTS
2014,2017-2018 Porsche Cayenne Platinum Edition
2003-2006,2008-2018 Porsche Cayenne S
2015-2018 Porsche Cayenne S E-Hybrid
2017-2018 Porsche Cayenne S E-Hybrid Platinum Edition
2011-2014 Porsche Cayenne S Hybrid
2010 Porsche Cayenne S Transsyberia
2003-2006,2008-2018 Porsche Cayenne Turbo
2006,2009-2010,2013-2014,2016-2018 Porsche Cayenne Turbo S
2007-2012,2014-2016 Porsche Cayman Base
2016 Porsche Cayman Black Edition
2016 Porsche Cayman GT4
2015-2016 Porsche Cayman GTS
2012 Porsche Cayman R
2006-2012,2014-2016 Porsche Cayman S
2008 Porsche Cayman S Sport
2011-2016 Porsche Panamera 4
2016 Porsche Panamera 4 Edition
2014-2016 Porsche Panamera 4S
2014-2016 Porsche Panamera 4S Executive
2011-2016 Porsche Panamera Base
2016 Porsche Panamera Edition
2014-2016 Porsche Panamera S
2014-2016 Porsche Panamera S E-Hybrid
2012-2013 Porsche Panamera S Hybrid
2005-2009 Volkswagen Touareg Base
2011-2015 Volkswagen Touareg Hybrid
2009-2011 Volkswagen Touareg TDI
2012-2016 Volkswagen Touareg TDI Executive
2012-2016 Volkswagen Touareg TDI Lux
2014 Volkswagen Touareg TDI R-Line
2012-2016 Volkswagen Touareg TDI Sport
2004 Volkswagen Touareg V6
2012-2016 Volkswagen Touareg V6 Executive
2012-2016 Volkswagen Touareg V6 Lux
2014-2015 Volkswagen Touareg V6 R-Line
2012-2016 Volkswagen Touareg V6 Sport
2010-2011 Volkswagen Touareg VR6
2014 Volkswagen Touareg X
